概要
Ubuntu上で動かしているVagrant(VirtualBox)環境で、 vagrant up
しようとしたところエラーが出たためその対応をおこなった際のメモです。
OSバージョン
$ cat /etc/issue
Ubuntu 22.04.3 LTS
カーネルバージョン
$ uname -r
6.5.0-14-generic
Vagrantバージョン
$ vagrant -v
Vagrant 2.4.0
VirtualBoxバージョン
$ VBoxManage --version
7.0.14r161095
エラー出力内容と対応
出力されたエラー
$ vagrant up
The provider 'virtualbox' that was requested to back the machine
'node' is reporting that it isn't usable on this system. The
reason is shown below:
VirtualBox is complaining that the kernel module is not loaded. Please
run `VBoxManage --version` or open the VirtualBox GUI to see the error
message which should contain instructions on how to fix this error.
VBoxManage --version
を実行
エラーに VBoxManage --version
を実行するようメッセージが出力されたため実行します。
$ VBoxManage --version
WARNING: The vboxdrv kernel module is not loaded. Either there is no module
available for the current kernel (6.5.0-14-generic) or it failed to
load. Please recompile the kernel module and install it by
sudo /sbin/vboxconfig
You will not be able to start VMs until this problem is fixed.
7.0.14r161095
sudo /sbin/vboxconfig
を実行
次に sudo /sbin/vboxconfig
を実行するようメッセージが出力されたため実行します。
$ sudo /sbin/vboxconfig
vboxdrv.sh: Stopping VirtualBox services.
vboxdrv.sh: Starting VirtualBox services.
vboxdrv.sh: Building VirtualBox kernel modules.
vboxdrv.sh: failed: Look at /var/log/vbox-setup.log to find out what went wrong.
There were problems setting up VirtualBox. To re-start the set-up process, run
/sbin/vboxconfig
as root. If your system is using EFI Secure Boot you may need to sign the
kernel modules (vboxdrv, vboxnetflt, vboxnetadp, vboxpci) before you can load
them. Please see your Linux system's documentation for more information.
/var/log/vbox-setup.log
を確認
エラーに /var/log/vbox-setup.log
を確認するようメッセージが出力されたため内容を確認します。
$ cat /var/log/vbox-setup.log
Building the main VirtualBox module.
Error building the module:
make V=1 CONFIG_MODULE_SIG= CONFIG_MODULE_SIG_ALL= -C /lib/modules/6.5.0-14-generic/build M=/tmp/vbox.0 SRCROOT=/tmp/vbox.0 -j8 modules
make[1]: warning: -j8 forced in submake: resetting jobserver mode.
warning: the compiler differs from the one used to build the kernel
The kernel was built by: x86_64-linux-gnu-gcc-12 (Ubuntu 12.3.0-1ubuntu1~22.04) 12.3.0
You are using:
make -f ./scripts/Makefile.build obj=/tmp/vbox.0 need-builtin=1 need-modorder=1
# cmd_mod /tmp/vbox.0/vboxdrv.mod
printf '%s
' linux/SUPDrv-linux.o SUPDrv.o SUPDrvGip.o SUPDrvSem.o SUPDrvTracer.o SUPLibAll.o common/string/strformatrt.o combined-agnostic1.o combined-agnostic2.o combined-os-specific.o | awk '!x[$0]++ { print("/tmp/vbox.0/"$0) }' > /tmp/vbox.0/vboxdrv.mod
# CC [M] /tmp/vbox.0/linux/SUPDrv-linux.o
gcc-12 -Wp,-MMD,/tmp/vbox.0/linux/.SUPDrv-linux.o.d -nostdinc -I./arch/x86/include -I./arch/x86/include/generated -I./include -I./arch/x86/include/uapi -I./arch/x86/include/generated/uapi -I./include/uapi -I./include/generated/uapi -include ./include/linux/compiler-version.h -include ./include/linux/kconfig.h -I./ubuntu/include -include ./include/linux/compiler_types.h -D__KERNEL__ -std=gnu11 -fshort-wchar -funsigned-char -fno-common -fno-PIE -fno-strict-aliasing -Wall -Wundef -Werror=implicit-function-declaration -Werror=implicit-int -Werror=return-type -Werror=strict-prototypes -Wno-format-security -Wno-trigraphs -mno-sse -mno-mmx -mno-sse2 -mno-3dnow -mno-avx -m64 -mno-80387 -mtune=generic -mno-red-zone -mcmodel=kernel -Wno-sign-compare -fno-asynchronous-unwind-tables -mfunction-return=thunk-extern -fno-jump-tables -mharden-sls=all -fpatchable-function-entry=16,16 -fno-delete-null-pointer-checks -O2 -Wframe-larger-than=1024 -fstack-protector-strong -Wno-main -fno-omit-frame-pointer -fno-optimize-sibling-calls -ftrivial-auto-var-init=zero -fzero-call-used-regs=used-gpr -pg -mrecord-mcount -falign-functions=16 -Wvla -Wno-pointer-sign -Wno-maybe-uninitialized -Wno-array-bounds -Wno-alloc-size-larger-than -Wimplicit-fallthrough=5 -fno-strict-overflow -fno-stack-check -fconserve-stack -Werror=date-time -g -gdwarf-5 -include /tmp/vbox.0/include/VBox/SUPDrvMangling.h -fno-omit-frame-pointer -fno-pie -Wno-declaration-after-statement -I./include -I/tmp/vbox.0/ -I/tmp/vbox.0/include -I/tmp/vbox.0/r0drv/linux -D__KERNEL__ -DMODULE -DRT_WITHOUT_PRAGMA_ONCE -DRT_OS_LINUX -DIN_RING0 -DIN_RT_R0 -DIN_SUP_R0 -DVBOX -DRT_WITH_VBOX -DVBOX_WITH_HARDENING -DSUPDRV_WITH_RELEASE_LOGGER -DVBOX_WITHOUT_EFLAGS_AC_SET_IN_VBOXDRV -DIPRT_WITHOUT_EFLAGS_AC_PRESERVING -DVBOX_WITH_64_BITS_GUESTS -DCONFIG_VBOXDRV_AS_MISC -DRT_ARCH_AMD64 -fsanitize=bounds-strict -fsanitize=shift -fsanitize=bool -fsanitize=enum -DMODULE -DKBUILD_BASENAME='"SUPDrv_linux"' -DKBUILD_MODNAME='"vboxdrv"' -D__KBUILD_MODNAME=kmod_vboxdrv -c -o /tmp/vbox.0/linux/SUPDrv-linux.o /tmp/vbox.0/linux/SUPDrv-linux.c ; ./tools/objtool/objtool --hacks=jump_label --hacks=noinstr --hacks=skylake --retpoline --rethunk --sls --stackval --static-call --uaccess --prefix=16 --module /tmp/vbox.0/linux/SUPDrv-linux.o
/bin/sh: 1: gcc-12: not found
make[2]: *** [scripts/Makefile.build:251: /tmp/vbox.0/linux/SUPDrv-linux.o] Error 127
make[1]: *** [Makefile:2037: /tmp/vbox.0] Error 2
make: *** [/tmp/vbox.0/Makefile-footer.gmk:133: vboxdrv] Error 2
エラーメッセージ内に /bin/sh: 1: gcc-12: not found
と出力され、
gcc-12
がインストールされていないため、ビルドエラーが出たと思われるため、次に現在インストールされているgccパッケージを確認します。
$ dpkg -l
ii gcc 4:11.2.0-1ubuntu1 amd64 GNU C compiler
ii gcc-11 11.4.0-1ubuntu1~22.04 amd64 GNU C compiler
ii gcc-11-base:amd64 11.4.0-1ubuntu1~22.04 amd64 GCC, the GNU Compiler Collection (base package)
ii gcc-12-base:amd64 12.3.0-1ubuntu1~22.04 amd64 GCC, the GNU Compiler Collection (base package)
gcc-12
パッケージがインストールされていないため、インストールします。
sudo apt -y install gcc-12
gcc-12
をインストールしたため、先程実行したコマンドを再実行します。
再度 sudo /sbin/vboxconfig
を実行
$ sudo /sbin/vboxconfig
vboxdrv.sh: Stopping VirtualBox services.
vboxdrv.sh: Starting VirtualBox services.
vboxdrv.sh: Building VirtualBox kernel modules.
エラーは出力されませんでした。
再度 /var/log/vbox-setup.log
を確認
ビルドが正常に完了していることが確認出来ました。
$ cat /var/log/vbox-setup.log
Building the main VirtualBox module.
Building the net filter module.
Building the net adapter module.
最後に vagrant up
も正常に実行出来ることが確認出来ました。
